至少组件
1 个钮体
1 个钮盖
1 套内置安装型套件
系统组件使产品完整
B8641008
Cover 41volcano
B8641009
Cover 41nero
B8641108
Supply 1 cover
关闭B8641108
Cover 41, with finger recessvolcano
B8641109
Supply 1 cover
关闭B8641109
Cover 41, with finger recessnero
B8741118
Supply 1 assembly kit
关闭B8741118
Assembly kit 41, flush fitting versionvolcano
B8741119
Supply 1 assembly kit
关闭B8741119
Assembly kit 41, flush fitting versionnero
“照明” 配件
B7546001
Board D=27 mm with 8 LEDs (RGB backlight), without controller, SMD technology, connecting cable 120 mm long, 4-pin socket at the end, incl. connector.
Recommended for:STAR-KNOBS 33 / 41
- flush-fitting version: only in conjunction with the diamond knob
- surface-mounted version: only in conjunction with the diamond assembly kit
CONTROL-KNOBS 36 with optional illumination
- installation in the bases available as accessories
Supply 1 LED illumination kit (RGB backlight)
关闭B7546001
LED illumination kit, 8 LEDs (RGB backlight)附件
A6207009
For fixing the potentiometers at front panels.
Suitable for
- round and wing knobs ø 10 - 16 with nut cover,
- round knobs ø 20 - 50 without nut cover,
- spindle-shaped knobs ø 16 - 40 with nut cover,
- Com-Knobs ø 16 - 50,
- Top-Knobs ø 20 - 40,
- Star-Knobs ø 33 & 41 and
- Control-Knobs ø 36 & 46.
Supply 1 round nut
关闭A6207009
Round nut M7 x 0.75A6210009
For fixing the potentiometers at front panels.
Suitable for
- round and wing knobs ø 10 - 16 with nut cover,
- round knobs ø 20 - 50 without nut cover,
- spindle-shaped knobs ø 16 - 40 with nut cover,
- Com-Knobs ø 16 - 50,
- Top-Knobs ø 20 - 40,
- Star-Knobs ø 33 & 41 and
- Control-Knobs ø 36 & 46.
Supply 1 round nut
关闭A6210009
Round nut M10 x 0.75A6295009
Suitable for
- round and wing knobs ø 10 - 16 with nut cover,
- round knobs ø 20 - 50 without nut cover,
- spindle-shaped knobs ø 16 - 40 with nut cover,
- Com-Knobs ø 16 - 50,
- Top-Knobs ø 20 - 40,
- Star-Knobs ø 33 & 41 and
- Control-Knobs ø 36 & 46.
Supply 1 round nut
关闭A6295009
Round nut 3/8"-32GA6300000
Supply 1 spanner
关闭A6300000
SpannerB8741001
Supply 1 assembly support
关闭B8741001
Assembly support 41green
